The EVO X Line brings the latest technology in a compact design with the highest quality components. From a pioneering technology, SounDigital brought to car audio amplifiers something that had not been explored yet. The thermal coupling through RTGP system.

The exclusive RTGP system (Thermal Recovery for power generation) assures SounDigital products both greater thermal efficiency and robustness with higher stability.

TECHNICAL SPECIFICATIONS

400.4 EVOX – 4Ω
Power @ 12.6V @ 4Ω: 4 X 66 WRMS
Power @ 12.6V @ 2Ω: 4 X 100 WRMS
Power @ 12.6V @ 1Ω: N/A
Bridge Power @ 12.6V @ 4Ω: 2 X 200 WRMS
Bridge Power @ 12.6V @ 2Ω: N/A
Power @ 14.4V @ 4Ω: 4 X 74 WRMS
Power @ 14.4V @ 2Ω: 4 X 112 WRMS
Power @ 14.4V @ 1Ω: N/A
Bridge Power @ 14.4V @ 4Ω: 2 X 223 WRMS
Bridge Power @ 14.4V @ 2Ω: N/A
Operating Voltage: 8V – 16V
Current Draw (Music): 19 A
Current Draw (Max): 39 A
Recommended Fuse (Music): 20 A
Total Efficiency: 82%
Damping Factor: 200
Frequency Response (-3dB): 5Hz – 22kHz
SNR: 88dB
Crossover HPF: 45Hz – 850Hz
Crossover LPF: 45Hz – 850Hz
THD N (10% Rated Power): 0.1%
Product Dimensions: 4.8 x 4.4 x 2.0 in
Product Dimensions: 12.3 x 11.3 x 5.1 cm
